Conformity Certificates

This certificate has been approved.

CCR Number

509149

Approved On

27 JULY 2025

Manufacturer

Toyota Motor Corporation

Motor Vehicle

TOYOTA HILUX (GUN122) 2.4L Pick-up RWD 4 Doors

Technical Specifications

Weights

Max Vehicle Weight

2810 kg

Curb

1800 kg

Maximum Axle Weight

Front

1200 kg

Rear

1750 kg

Dimensions

Length

5330 mm

Width

1800 mm

Height

1700 mm

Wheelbase

(F1–R1)

3085 mm

Track

Front

1510 mm

Rear

1510 mm

Body and Seating

Type of Chassis and Body

Chassis Frame

Number of Passengers

5 (including the driver)

Engine

Engine Type

Diesel

Cylinders

Displacement

2393 cc

Air Intake

Turbo

Net Engine Power

110 kW at 3400 rpm

Pollutant Limit

Comply with Euro5

Transmission

Manual

eCall System

Not Provided

Brakes

Service Brakes

Hydraulic

Emergency Brakes

Combined with the service brake

Fuel Economy

Motor Vehicle Class

Light Truck

Combined Fuel Economy

15.9 km/L — Excellent

Any other information or local standards to be complied

Also comply with the National regulations for member countries mentioned in the Annex of the list of Technical Regulations for MV 2025MY-D3, when exporting to those countries. The seating reference point of the lowest seat exceeds 700mm from the ground. This vehicle type complies with ECE13.This vehicle is only for Saudi Arabia, Kuwait and Qatar market.The length shown above is the vehicle W/Fr bumper(TypeA) and Rr bumper Steel step. W/Fr bumper(TypeB) and Rr bumper Steel step:5325mm. W/Fr bumper(TypeA):5270mm. W/Fr bumper(TypeB):5265mm.For UAE, LED head lamp (UN-ECE149) available.
